MBS.003019-S2
|
|
|
Sliding Binocular Head Inclined at 45°, 360° Rotatable
|
|
Eyepiece
|
Wide Field Eyepiece WF10×/ 18
|
|
Wide Field Eyepiece WF16×/ 11
|
|
|
Achromatic objective 4x
|
|
Achromatic objective 10x
|
|
Achromatic objective 40x
|
|
Achromatic objective 100x
|
|
|
|
|
|
Attachable mechanical stage 110×120mm/ 60x30mm
|
Double Layer Mechanical Stage, 140*140mm,
Moving Range 50*75mm
|
|
Condenser
|
N.A.1.25 Abbe Condenser, Iris Diaphargm, With Filter Holder
|
|
Focusing
|
Low Position Coaxial Coarse & Fine Focusing.
Fine Focusing Scale 0.002mm, With Tension Adjustment, With Up Limit
|
|
Filter
|
Blue filter
|
Blue filter
|
|
Green filter
|
Green filter
|
|
|
Yellow filter
|
|
|
Built-in Illumination, Halogen Lamp 6V/ 20W
|
|
Plan-concave Mirror
|
