MBS.001001Binocular Biological Student Microscope
  • /usr/575/images/Products/Y/57517767.jpg
  • /usr/575/Picture/Y/10908.jpg
  • /usr/575/Picture/Y/10909.jpg
  •

This microscope is the conveniently operated optical instruments with excellent functions and new pattern,it is very suitable for usage in medical test,teaching and microobservation in hospitals and schools.

  • With achromatic or semi-plan objectives
  • Infinity optical system available
  • Coaxial coarse/fine focusing system with tension adjustable and up stop
  • 6V 20W halogen lamp with brightness control
Specification
MBS.001001-2A
MBS.001001-2B
Eyepiece
WF10X(Φ18mm)
Head
Compensation binocular head inclination 30°
Objective
Achromatic 4X/0.10
Semi-plan 4X/0.10
Achromatic 10X/0.25
Semi-plan 10X/0.25
Achromatic 40X/0.65(Spring)
Semi-plan 40X/0.65(Spring)
Achromatic 100X/1.25(Spring, oil)
Semi-plan 100X/1.25(Spring, oil)
Focus System

Coaxial coarse/fine focus system, Minimum division of fine focusing: 2um
With tensional adjustable and up stop,
Nosepiece
Quadruple frontward ball bearing inner locatin
Stage
Double layer mechanical, size 135x125mm, moving range 75x35mm
Condenser
Abbe N.A.1.25 Rack & pinion adjustment
Filter
Blue filter
Frosted filter
Collector
For halogen lamp
Light source
6V 20W halogen lamp with brightness control

Item
Optional Accessories
Items No.
Eyepiece
Wide field WF16x/11mm
1051016
Divding 10x, 0.1mm/Div
1021010
Objective

Plan achromatic 4x/0.10
2040104
Plan achromatic 5x/0.12
2040105
Plan achromatic 10x/0.25
2040110
Plan achromatic 20x/0.40
2040120
Plan achromatic 40x/0.65(Spring)
2040140
Plan achromatic 60x/0.85(Spring)
2040160
Plan achromatic 100x/1.25(Spring, Oil)
2040111
Head


Monocular, inclination of 30°
010007
Binocular, inclination of 45°
011201
Trinocular, inclination of 45°
012201
Trinocular, inclination of 30°
012004
Dual viewing, inclination of 30°
013002
Nosepiece
Quintuple (Backward ball bearing inner locating)
032001
Filter
Green filter
115002
Yellow filter
115003
Light Source
LED collector, bright and white light
073008
Condenser
Dark field, dry
051001
Dark field, immersion
051002
Phase Contrast Attachment
Centering telescope
110001
Objective, Phase contrast plan 10x/0.25 PHP
2420110
Objective, Phase contrast plan 20x/0.40 PHP(Spring)
2420120
Objective, Phase contrast plan 40x/0.65 PHP(Spring)
2420140
Objective, Phase contrast plan 100x/1.25 PHP (Spring,oil)
2420111
PH-I Turnplate phase contrast condenser
052001
PH-II Turnplate phase contrast condenser
052004
Flashboard phase contrast set
052002
Pull board phase contrast set
052003
Infinity Optical System
Binocular head inclination of 30°
011102
Trinocular head inclination of 30°
012102
Centering telescope
110002
Objective, infinity plan achromatic 4x/0.10
2060104
Objective, infinity plan achromatic 10x/0.25
2060110
Objective, infinity plan achromatic 20x/0.25
2060120
Objective, infinity plan achromatic 40x/0.65(Spring)
2060140
Objective, infinity plan achromatic 100x/1.25(Spring, oil)
2060111
Objective, infinity phase contrast plan 10x/0.25 PHP
2470110
Objective, infinity phase contrast plan 20x/0.40 PHP (Spring)
2470120
Objective, infinity phase contrast plan 40x/0.65 PHP (Spring)
2470140
Objective, infinity phase contrast plan 100x/1.25 PHP (Spring, oil)
2470111
CCD adapter
0.4x
810001
0.5x
810004
1x
810002
0.5x with dividing 0.1mm/Div
810003
Camera
DV-1(With USB & video output)
800001
DV-2(With USB output)
800003
DV-3(With video output)
800005
Photography USB Output
1096001
Photography Video Output
1108001
Digital Camera Adapter
CANON Digital camera adapter(A610,A620,A630,A640)
820001
Photo Unit
2.5x/4x change over photograph attachment with 10x viewing eypiece
840001
4x focusing photograph attachment
840002
MD Adapter
840003
PK Adapter
840004
Polarizing Attachment
Polarizer 360° rotatable
111001
Analyzer
111101
Adapter
Input: 230V 50/60HZ Output: 9V 500mA
101001
Input: 110V 50/60HZ Output: 9V 500mA
101002
