MBL.003020-B
|
|
Head
|
Sliding Binocular Head, 45° Inclined |
Sliding Binocular Head, 45° Inclined, Anti-Mould System |
|
Eyepiece
|
Wide Field WF10x/18mm |
|
Nosepiece
|
Quadruple Nosepiece |
|
Objective
|
Achromatic 4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil)
|
|
Stage
|
Double Layer Mechanical Stage, 140*140mm, Mvoing Range 50*75mm |
|
Focusing
|
Coaxial Coarse & Fine Focusing. Fine Focusing Scale 0.002mm, Coarse Focusing Stroke 37.7mm/Rotation, With Tension Adjustment, With Up Limit |
| |
Rubber Cover On Focusing Knob
|
|
Condenser
|
N.A.1.25 Abbe Condenser, Iris Diaphargm, With Filter Holder |
|
Filter
|
Blue, Yellow, Green |
|
Light Source
|
Plan-Concave Mirror |
| Built-in Illumination 6V20W Halogen Lamp, 100~240V |
|
|
|
|
| Head |
Sliding Trinocular Head, 45° Inclined, Anti-Mould System |
| Seidentopf Binocular Head, 30° Inclined, Anti-Mould System |
| Seidentopf Trinocular Head, 30° Inclined, Anti-Mould System |
| Eyepiece |
Wide Field Eyepiece P16x/11mm |
| Nosepiece |
Quintuple Nosepiece |
|
