Sliding Binocular Head, 45° Inclined, 360° Rotatable
|
|
Eyepiece
|
Wide Field WF10x/18mm
|
|
Magnification
|
40x~1000x
|
|
|
Achromatic 4x/0.10
|
|
Achromatic 10x/0.25
|
|
Achromatic 40xs/0.65
|
|
Achromatic100xs/1.25(Oil)
|
|
|
Quadruple Nosepiece
|
|
|
Double Layer Mechanical Stage, 110*120mm, Mvoing Range 70*20mm
|
|
Condenser
|
Abbe Condenser N.A.1.2,
With Iris Diaphragm, With Blue Filter, Rack & Pinion Up/Down Adjustment
|
|
Focusing
|
Coaxial Coarse & Fine Focusing
|
|
Light Source
|
LED Lamp Illumination 1W, Brightness Adjustable
|
|
|
Dust Cover, Spare Bulb & Fuse
|
|
