MBL.003028Binocular/Trinocular Compound Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57517703.jpg
  •
  •
  •
  • With precision machining equipment and advanced alignment technics, making improvement on the bass of traditional microscope.
  • It is an ideal instrument in biological, histological, pathological field and can be widely used in academic demonstration and research.
Specification
MBL.003028-A
MBL.003028-B
Head
Monocular Head, 45° Inclined, 360° Rotatable
Seidentopf Binocular Head, 30° Inclined, 360° Rotatable, Interpupillary Distance 55~75mm
Eyepiece
Wide Field WF10x/18mm
Magnification
40x~1000x
Objective
Achromatic 4x/0.10
Achromatic 10x/0.25
Achromatic 40xs/0.65
Achromatic 100xs/1.25(Oil)
Nosepiece
Backward Quadruple Nosepiece
Stage
Mechanical Stage, Moving Range 60*30mm
Condenser
N.A.1.25 Abbe Condenser, Iris Diaphargm
Focusing
Coaxial Coarse & Fine Focusing
Light Source
Built-in 6V20W Halogen Lamp, Brightness Adjustable





Item
Optional Accessories
Eyepiece
P16x
