Specification
|
MBL.023085-B
|
MBL.023085-T
|
|
Head
|
30° gemel binocular, 360° rotatable, adjustable eye-point height 375-428.5mm,can adapt to operators of different heights,IPD 48-76mm | 30° gemel trinocular tube , 360° rotatable, spectroscopical ratio R:T=50:50 adjustable eye-point height 375-428.5mm,can adapt to operators of different heights.IPD 48-76mm |
|
Eyepiece
|
High eye point plan eyepiece PL10X22mm, diopter adjustable.
|
|
|
Objective
|
plan achromatic objective 4X/0.1,WD=15mm
|
plan achromatic objective 4X/0.1,WD=15mm
|
|
plan achromatic objective 10X/0.25,WD=10.8mm
|
plan achromatic objective 10X/0.25,WD=10.8mm
|
|
|
plan achromatic objective 40X/0.65,WD=0.8mm
|
plan achromatic objective 40X/0.65,WD=0.8mm
|
|
|
plan achromatic objective 100X/1.25,WD=0.21mm
|
plan achromatic objective 100X/1.25,WD=0.21mm
|
|
|
Nosepiece
|
Quintuple nosepiece
|
|
|
Focusing
|
Low position Coarse and fine coaxial,With tension adjustment and upper limit, Coarse adjustment stroke 27mm
|
|
|
Stage
|
Double layers mechanical ceramic paint stage, 210mmX171mm, precision: 0.1mm [X-axis rackless]; Clips for double sliders, moving range 78mm×51mm
|
|
|
Condenser
|
N.A.1.25 Koehler illuminator condenser（with socket for phase contrast and dark field accessories）with aperture diaphragm.
|
|
| Illumination | 3W LED with continuous intensity control. color temperature adjustment function, the adjustment range: 4750K-5500K, Type-c interface allows portable battery as a power source | |
| Power | 100V-240V External transformer | |
