MBP.003054Polarizing Microscope
  • /usr/575/images/Products/Y/57517722.jpg
  • /usr/575/Picture/Y/10751.jpg
  •
  •

MBP.003054 Transmit Polarizing Microscope, Newly designed with comfortable operating with ergonomic structure, with better illumination, convenient replacement of attachment with sliding-in center adjustable condenser.

Specification
MBP.003054
Head
Seidentopf Trinocular Head, 30° Inclined, Interpupillary 48~75mm, Diopter Adjustable
Optical System
Infinite optical system
Eyepiece

Plan Eyepiece EW10x/22mm, Eyepiece Tube Dia.30mm

Plan Eyepiece With Scale of Crosshair
Plan Eyepiece With Cross
Plan Eyepiece With Gridding
Objective
Strainfree Infinity Plan Achromatic Objective 4x/0.10/∞/- W.D.17.3mm
Strainfree Infinity Plan Achromatic Objective 10x/0.25/∞/0.17 W.D.10mm
Strainfree Infinity Plan Achromatic Objective 40x/0.65/∞/0.17 W.D.0.54mm
Strainfree Infinity Plan Achromatic Objective 100x/1.25/∞/0.17 W.D.0.13mm
Nosepiece
Backward Quintuple Nosepiece, Center Adjustable
Analyzer

1) 360° Dial Rotation Analyzer, Minimum Scale Reading 0.1° (Vernial Scale)
2) Switch Between Orthoscopic And Conoscopic Observation
3) Bertrand Lens Postion Adjustable
4) Optical Compensator: λ Slip (First Class Red), 1/4λ Slip, Quartz Wedge

Focusing
Coaxial Coarse & Fine Adjustment, Focusing Range 32mm, Fine Division 0.001mm, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.1mm Per Rotation
Stage

Polarizing Rotatable Stage, Dia.170mm, Center Adjustable
360° Scale, Minimum Division 1°
Minimum Reading 6' By Means of Vernial Scale
45° Click Stop Knob

Condenser
Strainfree Swing Condenser N.A.0.95/0.25
Polarizer
360° Rotatable, 0° Position Adjustable
Filter
Blue Filter, Dia.45mm
Illumination
Transmit Illumination Halogen Lamp 24V100W, Brightness Adjustable

Item
Optional Accessories
Objective
Strainfree Infinity Plan Achromatic Objective 20x/0.4/∞/- W.D. 5.1mm
Stage
Attachable Stage, Moving Range 30*40mm
Filter
Netural Filter ND25
Netural Filter ND6
Adapter
Photo Adapter
C-Mount 1.0x
C-Mount 0.5x
