MBI.001006Inverted Microscope

This inverted microscope is equipped with wide field eyepieces, long working distance plan achromatic objectives, long working distance condenser and phase contrast unit. It can observe transparent and unfinished living specimen in culture bottle or culture utensil. It is the ideal tools for research of living specimen structure, liquid, deposits and so on.

Wide field eyepiece, long working distance, plan achromatic objectives
Equipped with phase contrast unit, include long working distance condenser, phase contrast objective and centering telescope
Coaxial coarse/fine focus system with tensional adjustable and up stop, minimum division of fine focusing 2um
6V 20W halogen lamp with brightness control

Specification	MBI.001006
Eyepiece	WF10X(Φ20mm)
Head	Trinocular, inclination of 30°,100% image light for photography capable
Objective	Long working distance plan achromatic PLL10x/0.25
	Long working distance plan achromatic PLL25x/0.40
	Long working distance plan achromatic PLL40x/0.60
	Long working distance plan achromatic phase contrast PLL10x/0.25 PHP
Shelf of Specimen	Match to installΦ68mm, or 77x33mm culture utensil
Shelf of Specimen	Match to installΦ68mm culture utensil
Focus System	Coaxial coarse/fine focus system, with tensional adjustable and limit stopper, minimum division of fine focusing: 2 μm
Nosepiece	Quadruple ball bearing inner locating
Stage	Double layer mechanical, size 200x152mm, moving range 75x30mm
Filter	Blue filter
	Green filter
	Frosted filter
Light Source	6V 20W halogen lamp with brightness control
Impellent Style Phase Contrast Unit	Centering telescope
	10x impellent style phase plate
	Condenser rack & pinion adjustable, NA=0.4, working distance 30mm

Item	Optional Accessories		Item No.
Eyepiece	Wide field WF16x/11mm		1051016
	Divding 10x/20mm, 0.1mm/Div		1120010
Nosepiece	Quintuple (Ball bearing inner locating)		032001
Condenser	Ultra long working distance, working distance 70mm		050006
Filter	Yellow filter		115003
Impellent Style Phase Contrast Unit	Objective	Long working distance plan phase contrast objective PLL25x/0.40 PHP	2430125
		Long working distance plan phase contrast objective PLL40x/0.60 PHP	2430140
	Impellent Phase plate	25x	112002
		40x	112003
Sliding Phase Contrast Unit	Objective	Long working distance plan phase contrast objective PLL10x/0.25 PHP2	2430310
		Long working distance plan phase contrast objective PLL25x/0.40 PHP2	2430325
		Long working distance plan phase contrast objective PLL40x/0.60 PHP2	2430340
	Sliding Phase Plate	10x	112004
		25x/40x	112005
	Condenser rack & pinion adjustable, NA=0.4, working distance 55mm		050007
CCD Adapter	0.4x		812001
	0.5x		812004
	1x		812002
	0.5x with dividing 0.1mm/Div		812003
Photo Adapter	2.5x/4x change over photograph attachment with 10x viewing eypiece		840001
	4x focusing photograph attachment		840002
	MD adapter		840003
	PK adapter		840004
