Eyepiece |
|
|
Head |
Inclination angle is 45Degree interpupillary distance is 53~75mm.
|
Infinity, Long Working Distance Plan Achromatic Objective
|
PLL 10X0.25 Work distance:4.3 mm,Cover glass thickness:1.2mm
|
PLL 20X0.40 Work distance:8.0 mm,Cover glass thickness:1.2mm
|
PLL 40X0.60 Work distance:3.5 mm,Cover glass thickness:1.2mm
|
PLL 10X0.25 PHP2 Work distance:4.3 mm,Cover glass thickness:1.2mm .Phase Contrast Objective
|
Shelf of Specimen |
Match to installΦ68mm, or 77x29mm culture utensil
|
Match to install 82x57mm culture utensil
|
Match to install 128x85mm 96 holes culture utensil
|
|
Coaxial coarse/fine focus system, with tensional adjustable and limit stopper, minimum division of fine focusing: 2 μm
|
|
|
Stage |
Fixed stage overall size is 227mmX208mm
|
Glass rotundity stage overall size Dia:118mm
|
Mechanical moving device, moving range is 77mm (longitudinal)X114mm (transverse)
|
Culture dish holder 1
|
Inside locating slot size: 86mm (W)X129.5mm (L), optional with a circular culture dish Dia 87.5mm
|
Culture dish holder 2
|
Inside locating slot size: 34mm (W)X77.5mm (L), optional with a circular culture dish Dia 68.5mm
|
Culture dish holder 3
|
Inside locating slot size:57mm (W)X82mm (L)
|
Filter |
|
Green filter
|
|
Light Source
|
6V30W halogen, brightness enable control
|
Sliding Phase Contrast Unit
|
|
10x impellent style phase plate
|
Condenser rack & pinion adjustable, NA=0.4, working distance 30mm
|
