MMU.003045-B
|
|
Head
|
Seidentopf Trinocular Head Inclined at 30°, Interpupillary 48-75mm
|
|
Optical System
|
Infinity Optical System, Bright Field/Dark Field, DIC, Polarizing
|
|
Eyepiece
|
Extra Wide Field Eyepiece EW10x/22mm, Eyepiece Tube Dia.30mm
|
|
|
Infinity Plan Achromatic Objectives 5x/ 0.12/ ∞/ - (BF/DF),W.D.12mm
|
|
Infinity Plan Achromatic Objectives 10x/ 0.25/ ∞/ - (BF/DF),W.D.10mm
|
|
Infinity Plan Achromatic Objectives 20x/ 0.4/ ∞/0 (BF/DF),W.D.4.3mm
|
|
Infinity Plan Achromatic Objectives 50x/ 0.75/ ∞/0 (BF/DF),W.D.0.32mm
|
|
Infinity Plan Achromatic Objectives100x/0.80/∞/0 (BF/DF),W.D.2mm
|
| |
Infinity Plan Achromatic Objectives 40x/0.65/∞/0.17,W.D.0.54mm
|
| |
Infinity Plan Achromatic Objectives 100x/1.25/∞/0.17,W.D.0.13mm
|
|
|
Backward Quintuple Nosepiece
|
|
Focusing
|
Coaxial Coarse & Fine Adjustment, Fine Focusing Precision <1um, With Safty Stop, With Tension Adjustment
|
|
|
Maximum Sample Height 50mm
Non-Porous Double Layer Mechanical Stage 186*138mm, Moving Range 74*50mm, Including:
|
Maximum Sample Height 30mm
Double Layer Mechanical Stage 186*138mm, Moving Range 74*50mm, Including:
--Specimen Preparation Plate
--Slide Glass
|
|
Reflect Illumination
|
24V 100W Halogen Light, Brightness Adjustable
Kohler Illumination With Aspherical Condenser
Polarizer & Analyzer, Intergrate Board For Polarizer & Analyzer
Blue, Green, Yellow Filter, Gound Glass
|
|
Transmit Illumination
|
|
Swing-Out Condenser N.A.0.9/0.25
24V 100W Halogen Light With Aspherical Condenser
Blue Filter
|
