MMU.001010Upright Metallurgical Microscope
  • /usr/575/images/Products/Y/57517781.jpg
  • /usr/575/Picture/Y/10826.jpg
  • /usr/575/Picture/Y/10827.jpg
  •

This reflected metallurgical microscopes is suitable to observe the microscopeical surfaces of non-transparent object. Equipped with large move range mechanical stages, reflected vertical illumination and set polarizer device in trinocular head, it has clear and high contrast picture beautiful sculpt.
It is deal instruments in research work in biology, metallography, mineralogy,precision engineering, electronics and etc.

  • Plan achromatic objectives with long working distance (no cover glass)
  • Large move range mechanical stage, move quickly and slowly as you need
  • Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 7μm
  • 6V 20W halogen lamp, brightness control.
  • Trinocular head can switch to observe normally or to observe the Polarize, can send 100% of light to the binocular eyepieces or to the top port.
Specification
MMU.001010-A
MMU.001010-B
Eyepiece
Wide field eypieceWF10X(18mm)
Head
Trinocular, Inclination of 30°(Analyzer with field diaphragm to switch)
Objective
Plan achromatic objectives with long working distance (no cover glass) PL 5X/0.12, working distance 18.3mm
Plan achromatic objectives with long working distance (no cover glass) PLL10X/0.25 , working distance 8.9mm
Plan achromatic objectives with long working distance (no cover glass) PLL20X/0.40, working distance 8.7mm
Plan achromatic objectives with long working distance (no cover glass) PLL40X/0.60, working distance 3.7mm
Plan achromatic objectives with long working distance (no cover glass) PLL80X/0.80(Spring), working distance 0.96mm
Focus System
Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing:2um
Nosepiece
Quintuple (Frontward ball bearing inner locating)
Stage

Three layer mechanical,size:250x230mm,
moving range 154x154mm

Three layer mechanical,size:280x270mm,
moving range 204x204mm

Reflected Illumination Unit
Vertical illumination with field diaphragm, aperture diaphragm and polarizer, (Y,B,G) filter and frosted filter
6V 20W halogen lamp with brightness control

Item
Optional Accessories
Eyepiece
Wide field WF16X(Φ11mm)
Dividing 10X(Φ18mm) 0.1mm/Div
Objective
Plan achromatic objectives with long working distance (no cover glass) PLL 50X/0.70, Working distance:2.02mm
Plan achromatic objectives with long working distance (no cover glass) PLL 60X/0.75 Working distance:3.7mm
Plan achromatic objectives with long working distance (no cover glass) PLL 100X/0.85 (Spring) Working distance:0.4mm
Plan achromatic objectives (no cover glass)
PL 100X/1.25 (Spring, oil) Working distance:0.3mm
CCD adapter

0.4x
0.5x
1x
0.5x with dividing 0.1mm/Div
Photo Adapter
2.5x/4x change over photograph attachment with 10x viewing eypiece
4x Focusing photograph attachment
MD adapter
PK adapter
DC Adapter
Digital Camera Adapter for CANON(A610,A620,A630,A640)
