MMU.040028Binocular/Trinocular Upright Metallurgical, 40X~400X

This equipment can be used in observation, analysis and research of Metallurgy, Mineral, Crystal, Micro-electronics and it is the first choice for the factories, universities, research institutions and electronic industry.
It is adopted 2 kinds of illumination of reflection and transmission and also equipped with Epi-illumination Polarization devices. Under the reflected light, it can proceed Bright field and Polarizing observation.
It can also proceed Bright field observation under transmitted illumination. Stable, high-quality optical systems meet your requirement of high image quality, square-built body represents more rigid, T-shaped design gives you a more stable base. Humanized configuration design and convenient operation, Let you release form the pressure of heavy work. Let you devote experiment with entire energy.

Specification	MMU.040028-B	MMU.040028-T
Head	Compensation Free Binocular,30°inclined,55mm-75mm	Compensation Free Trinocular,30°inclined,55mm-75mm
Eyepiece	Wide field WF10X/22mm
	Wide field WF10X/20mm with Crosshair 0.1mm
Objective	Infinity Metallurgical Objective 4X/0.1 W.D. 29.4mm
	Infinity Metallurgical Objective 10X/0.25 W.D. 16mm
	Infinity Metallurgical Objective 20X/0.4 W.D. 10.6mm
	Infinity Metallurgical Objective 40X/0.6 W.D. 5.4mm
Nosepiece	Quadruple
Focusing	Coaxial coarse & fine adjustment system, range 28mm, fine division 0.002mm
Stage	Double Layer Mechanical, (Size180mmX150mm,Moving Range:75mmX50mm)
Condenser	Abbe condenser N.A.1.25 with Iris diaphram & filter
Flashboard Filter	Blue Filter
	Green Filter
	Neutral Filter
Checking Tool	0.01mm Micrometer
Polarizing Device	Analyzer rotatable 360°, Polarize &Analyzer can be Mmoved in/out of the Optical Path
Light Source	12V/30W,AC 85V-230V
Illumination	EPI-Kohler Illumination with Apertrue Iris Diaphragm and Field Iiris Diaphragm
	Transmission Light,Adjustble Brightness

Item	Optional Accessories
Eyepiece	Micrometer Eyepiece
Objective	Long Working Distance 5.1mm PL L50X/0.55B.D.
	Long Working Distance 4mm PL L80X/0.75B.D.
	Long Working Distance 3mm PL L100X/0.8B.D.
CCD Adapter	0.5X
	0.57X
	0.75X
Photo Adapter	Photo Adapter
Planishing Tool	Planishing Tool
CCD	CCD Camera,colour 1/3" High Resolution 520 TV lines
Software	Two-dimensional Measurement Software
Software	Professional Metallurgical Iimage Analysis Software
