MMI.040021Inverted Metallurgical, Binocular/Trinocular,195 Metallurgical Objective, 40X~400X
  • /usr/575/images/Products/Y/57519574.jpg
  •
  •
  •

MMI.040021 is equipped with 195 Metallurgical Objective 4X/10X/20X/40X

If you want choose Infinity Metallurgical Objective 4X/10X/20X/40X model, pls find MMI.040022

  • This series microscope is widely used in observation & analysis of metallurgical organization in Mechanical industry, Research of Geological & Mineral department and viewing & measuring crystal, integrate circuit, micro-electronics, etc in Electronic industry.
  • It is the first choice of Factories, Academy, Scientific research organization contrast image.
  • Novel figure and superior craftsmanship keep abreast of the tidal current much more.Humanized configuration design and simple operation, Let you release from the pressure of heavy work
Specification
MMI.040021-B
MMI.040021-T
Head
Compensation Free Binocular,45°inclined,50mm-75mm
Compensation Free Trinocular,45°inclined,50mm-75mm
Eyepiece

Wide field WF10X/20mm
Wide field WF10X/20mm with crosshair 0.1mm
Objective
195 Metallurgical Objective 4X/0.1 W.D. 25mm
195 Metallurgical Objective 10X/0.25 W.D. 11mm
195 Metallurgical Objective 20X/0.4 W.D. 9mm
195 Metallurgical Objective 40X/0.6 W.D. 3.8mm
Nosepiece
Quintuple
Focusing
Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm.
Stage
Double Layer Mechanical, Central Stage: Φ110mm (Size242mmX172mm,Moving Range:75mmX50mm)
Flashboard Filter
Blue Filter
Green Filter
Yellow Filter
EPI-Kohler Illumination EPI-Kohler Illumination,Apertrue Iris Diaphragm and Field Iris Diaphragm
Light Source 12V/30W,AC 85V-230V Halogen Bulb,Adjustble Brightness
Polarizing Device Analyzer Rotatable 360°, Polarize &Analyzer can be moved in/out of the Optical Path
Checking Tool 0.01mm Micrometer

Item
Optional Accessories
Objective 50X/0.75 W.D.0.9mm
80X(S)/0.9 W.D.0.9mm
Photo Adapter Photo Adapter
