Inverted Metallurgical, 100X~400X, UCIS infinity optical system

MMI.038008Inverted Metallurgical, 100X~400X, UCIS infinity optical system

UCIS Infinity Independent Achromatic Optical System
It is widely used in cytology, parasites, oncology, immunology, genetic engineering, industrial microbiology, botany and other fields.

Specification	MMI.038008
Optical System	UCIS infinity independent achromatic optical system
Head	Seidentopf trinocular head, 30° inclined, interpupilary distance 52-75mm, diopter adjustable
Eyepiece	Plan WF10x/20mm, high eyepoint up to 21mm,
Objective	Infinity LWD plan achromatic objective 10x
	Infinity LWD plan achromatic objective 20x
	Infinity LWD plan achromatic objective 40x
	Infinity LWD plan phase contrast objective 20x
Nosepiece	Quintuple, reversed type with positive click stops
Focusing	Coaxial coarse and fine focus mechanism with markings, fine focus sensitivity 1μm, coarse range 14mm
Stage	Low position, mechanical stage, size 180x150mm, moving range 80x50mm.
	Drop specimen holder(φ110)
	Specimen holder
Centering Attachment	Centering telescope
Phase Contrast	Phase contrast slider (for 10x/20x/40x phase contrast and brightfield observation)
Light Source	250V/3.15A Φ5x20 fuse
	6V30W Halogen bulb
	6V30W Halogen lamp house
	Electrical parts for 6V30W halogen lamp
	Abbe condenser N.A. 0.30 with iris diaphragm, with phase contrast slider, long work distance 72mm
	Power supply 110-240V 50/60Hz
Filter	Blue filter (Φ34)
	Green filter (Φ34)
	Yellow filter (Φ34)
Frame	One-piece construction from arm to base
Other	Allen screw driver 2mm
	Power cord
	Dust cover

Item	Optional Accessories
Eyepiece	Eyepiece 16x/13mm, plan
	WF10x/18mm, plan, reticule eyepiece, high eyepoint up to 21mm diopter adjustable
	WF10x/22mm,plan, high eyepoint
	WF10X/20mm, reticule eyepiece, high eye-point, diopter adjustable
Head	Seidentopf binocular head, 30° inclined, interpupillary distance 52-75mm, diopter adjustable
	Seidentopf binocular head, 30° inclined, interpupillary distance 52-75mm, diopter adjustable (for FOV 22mm)
	Seidentopf trinocular head, 30° inclined, interpupillary distance 52-75mm, diopter adjustable (for FOV 22mm)
Objective	Infinity LWD plan achromatic objective 4x
	IInfinity LWD Plan Achromatic Objective 60x
	Infinity LWD plan phase-contrast objective 10x (positive)
	Infinity LWD plan phase-contrast objective 40x (positive)
	Infinity LWD Plan Phase-Contrast Objective 10x (Negative)
	Infinity LWD Plan Phase-Contrast Objective 20x (Negative)
	Infinity LWD Plan Phase-Contrast Objective 40x (Negative)
Stage	Fixed Stage, Size 240x180mm
Adapter	0.25x C-Mount (suitable for 1/3" CCD)
	0.5x C-Mount
	1.0x C-Mount
	Digital Camera Adapter, (Need To Know Camera Model Number)
Fluorescence Attachment	100W Mercury lamp house
	100W Power supply unit
	100W Mercury lamp
	100W Mercury lamp (Osram)
	Excitation filter B
	Excitation filter G
	Excitation filter UV
	Excitation filter V
	Fluorescence illuminator
