Head
|
Seidentopf Binocular Head, 30° Inclined, 360° Rotatable
|
|
Eyepiece
|
WF10x, P16x
|
|
|
Achromatic Objective 4x
|
|
Achromatic Objective 10x
|
|
Achromatic Objective 40x
|
|
Achromatic Objective 100x
|
|
|
Backward Quadruple Nosepiece
|
|
Focusing
|
Coaxial Coarse & Fine Focusing Adjustment
|
|
|
Double Layer Mechanical Stage, 140*140mm, Moving Range 50*75mm
|
|
Condenser
|
Abbe Condenser N.A.1.25, With Iris Diaphragm & Filter, Rack & Pinion Adjust
|
|
Fluorescent System
|
Reflected Flourescent System
-- Power Supplier Box, 220V/110V Interchangeable, Digital Display
-- 100W HBO Ultra Hi-Voltage Spherical Mercury Lamp
-- Barrier To Resist Ultraviolet Light
-- Fluorescent Free Oil
-- Fluorescent Free Objective 4x,10x,40x,100x
-- Excitation Filter Blue, Green
|
|
Illumination
|
Built-in Halogen Lamp 6V/20W , with Continue Intensity Control, 110V/220V
|
|
