Monocular Zoom Microscope, With wider viewing field, digital camera to connect to computer or TV, can be widely used in electronic industry, educational demonstration and agriculture for micro object observation, inspection and measurement.
Specification
MSM.003066-A
MSM.003066-B
Magnification
Main Body 0.7~4.5x, With Eyepiece Up To 7~45x. With 15" Monitor Up to 400x
Zoom Ratio
1:6.5
Eyepiece
Eyepiece WF10x
Working Distance
90mm
Stand
Black Square Stand, Size 220*280mm, Focusing Range 55mm
White Square Stand, Size 220*280mm, Focusing Range 55mm
Light Source
Upper Ring Fluorescent Light
Upper Ring LED Light, Brightness Adjustable
Adapter
C-Mount Adapter
Digital Camera
1/3" CMOS Digital Camera 380 TV Lines VGA Output, NTSC/PAL Optional
1/4" CMOS Digital Camera 300K Pixels, Resolution 640*480 USB 2.0 Output, VGA Output
Item
Optional Accessories
Auxiliary Lens
0.3x
0.5x
2.0x
0.45x Medium Adapter
Stage
Manual Working Stage 145*195mm, Moving Range 50*50mm
