MSD.001049Step Zoom Stereo Microscope, 10X/20X/30X/40X
  • /usr/575/images/Products/Y/57517780.jpg
  • /usr/575/Picture/Y/10820.jpg
  • /usr/575/Picture/Y/10821.jpg
  •

The series stereo microscopes is a kind of positive image microscope; it have long working distance, clear and smooth image quality, wide field, convenience operation etc. It can be used for culture and education, scientific research, farming and forestry, electronics and precision machine industries widely.

  • Eyepiece is Wide Field 20mm, including 2 objectives
  • Optical head 45° inclination, 360° rotatable, interpupillary distance 55~75mm, eyepiece tube diopter adjustable
  • Series are equipped with up light source
Specification
MSD.001049-A2
MSD.001049-A21
MSD.001049-B2
MSD.001049-B21
Eyepiece
WF10x/20mm
Objectives
1x/3x
2x/4x
Total Magnification
10x/30x
20x/40x
Visual Field
Dia 20~6.7mm
Dia.10~5mm
Working Distance
88mm
Stand & Base
Track Stand
Pole Stand
Track Stand
Pole Stand
Up/down Move Range
88mm<=h<265mm
88mm<=h<130mm
Base
Base size 215x160x60mm
Illumination
Up light source 12V10W halogen lamp, reflector cup, brightness adjustable

Item
Optional Accessories
Eyepiece
Divisional wide field eyepiece 10X/20mm 0.1mm/Div
