MSZ.023056Step Zoom Stereo Microscope, 5X~120X
  • /usr/575/images/Products/Y/57518222.jpg
  •
  •
  •
  • Standard magnification is 10X~30X.
  • Standard working distance is 110mm.
  • Viewing Head 45Inclined,each tube allows interpupillary distance and diopter adjustments to suit the user.
  • Ergonomic design and turret knobs for magnification change.
Specification
MSZ.023056
Standard Magnification 10X / 30X
Max Magnification 120X=(Turret objective 3X)+(Optional eyepiece-WF20X)+(Optional auxiliary Lens 2X)
Min Magnification
5X=(Turret objective 1X)+(Eyepiece-WF10X)+(Optional auxiliary Lens 0.5X)
Head
Binocular head (ST7013)
Eyepiece
Wide field, high-eyepoint eyepiece-WF10X23mm
Objective
1X/110mm
3X/110mm
Focusing Arm ST70A1
Base
SZSTL1(match with all standard focusing arm)

Item
Optional Accessories
Head
Trinocular head
Eyepiece Wide field, high-eyepoint eyepiece WF15X16mm
Wide field, high-eyepoint eyepiece WF20X12mm
Auxiliary Objective


0.5X/165mm

1.5X/45MM

2X/30mm
Photo Adapter 3.2X Photo Eyepiece, Photo tube (with PK or MD Mount) ST70PH
CCD Adapter 0.35x, for 1/3" C-mount, focusing adjustable
Dark Field Dark Field Condensor SZDCd1
