MLB.003084Biological LCD Microscope,8"LCD,1000X
  • /usr/575/images/Products/Y/57518102.jpg
  • /usr/575/Picture/Y/11165.jpg
  •
  •
  • MLB.003084 is easy to use and can be widely used in various optical micro fields,such as teaching、researching、electronic checking and so on.
  • A new generation microscope with Android OS,just like a tablet.
  • Support Wifi and Bluetooth,it is easy to extend the application.
  • With 8 inch IPS LCD screen,A7 dual core 1.6G processor,support for 5 point touch,HDMI video output and SD card expansion.
Specification
MLB.003084
LCD Screen
8 Inch TFT Touching Screen,1280X720
Image Sensor
3.0 Mega Pixels CMOS Chip
Digital Interface
USB2.0、Mini USB, HDMI , Support Wifi and Bluetooth ,Support SD Card
Head
Compensation Free Binocular Head, Inclined at 30°, Interpupillary 52-75mm
Eyepiece

Wide Field Eyepiece WF10x/18mm

Objective
Infinite Semi-Plan Achromatic Objective 4x
Infinite Semi-Plan Achromatic Objective 10x,
Infinite Semi-Plan Achromatic Objective 40x
Infinite Semi-Plan Achromatic Objective 100x
Nosepiece
Quadruple Nosepiece
Focusing
Coaxial Coarse & Fine Adjustment, Moving Range 20mm
Stage
Double Layer Mechanical Stage, Size 140x140mm, Moving Range 75x50mm
Condenser
Sliding-in Centerable Condenser N.A.1.25
Illumination
 LED collector, bright and white light
Software
TouchScope
Operating Syetem
Android 4.2.2
