MLF.003088LCD Fluorescent Microscope, 9"LCD, 5M CMOS, HDMI, 40X~1000X
  • /usr/575/images/Products/Y/57518576.jpg
  • /usr/575/Picture/Y/11528.jpg
  •
  •
  • MLF.003088 is equipped with WF eyepiece and modern way of electronic imaging. It’s not only features for high resolution pictures and multi functions, but also features for simple and convenient operation. It’s suitable to observe and study microorganisms, cells bacteria, and tissue observation and research.
  • It is widely used in medical units, universities, research institution, disease control and agriculture and pastoral sector.
Digital Part
Specification
MLF.003088 9"LCD 5M CMOS Fluoresent Microscope

LCD Screen

9" HD LCD Screen, 1280X800
Image Sensor 5.0 Mega
Photo Resolution 2560X1920
Video Resolution 1280X720/30FPS
Data Output HDMI
Storage 4G SD Card
Date Mode Year, Month, Day, Hour, Minute
Measurement Crosshair and Arrow (Black,White,Red,Green,Blue)
Language

Nine Languages (English,Germany,French,Spanish,Russia,
Janpanese,Korean,Latin,Arabic)

Coordinate Colors Black/White/Red/Blue/Green

Optical Part
Specification
MLF.003088 9"LCD 5M CMOS Fluoresent Microscope
Optical System
Infinity Optical System
Viewing Head

Compensation Free Binocular Head,Inclined 30°Interpupillary Distance 55-75mm

Eyepiece
W10x18mm,with Diopter Adjustable
Objective
Infinity Plan Achromatic Objective 4x
Infinity Plan Achromatic Objective 10x
Infinity Plan Achromatic Objective 40x
Infinity Plan Achromatic Objective 100x
Nosepiece
Backward Quintuple Nosepiece
Stage
Double Layer Mechanical Stage, 140*140mm, Moving Range 50*75mm
Focusing

Coaxial Coarse/Fine Focus System with Tension adjustable, Limit Stopper Range24mm, FineDivision0.002mm

Condenser

NA1.25 Abbe Condenser with Iris Diaphragm & Filter(Blue and Green),Rack & Pinion Adjustment

Filter
Blue Filter
Green Filter

Reflected Light Source

Blue, Green Exciting Light Filter System and O Ordinary Light System

Illumination
3.7V,3W LED Lamp,Brightness Adjustable

Lamp

100W HBO Ultra Hi-voltage Spherical Mercury Lamp

Protection Barrier

Barrier to Resist the Ultraviolet Light

Power Supplier

Power Supplier NFP-1, AC Input 220V/ 110V (Interchangeable), Digital Display and Timer

Immersion Oil

Fluorescent Free Oil
