LCD Biological Microscope, 9" LCD, 5M CMOS, HDMI, 40X~400X

Home > Products > LCD Microscope > LCD Biological Microscope

MLB.003090LCD Biological Microscope, 9" LCD, 5M CMOS, HDMI, 40X~400X

MLB.003090 is for medical and health units, university, research, institution to observe and research micro-organisms, cells, bacteria, tissue culture, suspended substance, sediments and so on, especially for continuous observation of cells, bacteria in cultivation liquid. And the microscope can easily snap shot the growing and dividing process. It is widely used for cytology, parasites, oncology, immunology, genetic engineering, industrial microbiology, botany and etc.

Digital Part	LCD Screen	9 HD Inches, Resolution is 1280*800
	Image Sensor	5.0 Mega
	Photo Resolution	2560X1920
	Video Resolution	1280X720/30FPS
	Data Output	HDMI
	Storage	4G SD Card
	Date Mode	Year, Month, Day, Hour, Minute
	Measurement	Crosshair and Arrow (Black,White,Red,Green,Blue)
	Language	Nine Languages (English,Germany,French,Spanish,Russia, Janpanese,Korean,Latin,Arabic)
	Coordinate Colors	Black/White/Red/Blue/Green

Optical Part	Specification	MLB.003090 9" 5.0M LCD Inverted Biological Microscope
	Head	Seidentopf Trinocular Head, 30° Inclined, Interpupillary 55~75mm, Diopter Adjustable
	Optical System	Infinite optical system
	Eyepiece	Extra Wide Field Eyepiece EW10x/18mm, High Eyepoint
	Objective	Infinity Plan LWD Achromatic Objective 4x/0.1, W.D.18mm
		Infinity Plan LWD Achromatic Objective 40x/0.6, W.D.2.6mm,Cover Glass 1.2mm
		Infinity Plan Phase Contrast Achromatic Objective PH10x/0.25, W.D.10mm
		Infinity Plan Phase Contrast Achromatic Objective PH20x/0.40, W.D.5.1mm
	Nosepiece	Quintuple Nosepiece
	Focusing	Coaxial Coarse & Fine Adjustment, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.2mm Per Rotation
	Stage	* Plain Stage 160250mm Glass Insert Plate * Auxiliary Stage 70*180mm
	Condenser	ELWD Condenser N.A.0.3, Long Working Distance 72mm, Up to 150mm Without Condenser
	Phase Contrast	Phase Contrast Slide, 2 Holes For 10x-20x Objective
	Filters	Green, Blue, Ground Glass, Dia.45mm
	Illumination	External Kohler Illumination, Halogen Lamp 6V30W, Brightness Adjustable

Item	Optional Accessories
Objective	LWD Infinity Plan Achromatic 10X
	LWD Infinity Plan Achromatic 20X
	Infinite Plan Phase Objective PH40×/0.65,WD0.35mm
Phase Annulus	40×Phase Annulus Plate
Stage	Attachable Mechanical Stage, X-Y Coaxial Control，Moving Rang 120×78mm
	Terasaki Holder
	Φ38mm Petri Dish Holder
	Φ54mm Slide Glass Holder
