9.7" LCD Pad with Andriod System of MLB.017015
|
Specification of LCD PAD
|
LCD Screen |
9.7" , Resolution 2048*1536 , Touch Screen |
| CPU |
1.8GHz Four Core |
| RAM |
2GB |
| Data Storage |
TF Card Slot |
| Data Interface |
HDMI,WiFi,USB 2.0 |
| Operation System |
Android 6.0 System, Multi Language |
| Power |
Wide Voltage AC 100~240V, DC 12V/2A with External Power Adaptor |
| Software |
YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed |
| Product Size |
Pad 18.2*23.8*5.1cm |
| Package Size |
Packing Box 10*24*29cm, 1 pc/Box |
| Specification of Digital Camera |
Senser |
1/2.5" Color CMOS |
|
Resolution
|
5.0M Pixels, Maximum Photo Resolution 2592*1944 |
| Pixel Size |
2.2um*2.2 um |
| Effective Image Size |
5.70(H) * 4.28(V)mm, (7.23mm Diagonal) |
| Frame Rate |
2592*1944@14 Fps, 640*480@124Fps |
| Dynamic Range |
38.5dB |
| ADC |
12 Bit, On Chip |
| White Balance |
Auto |
| Connect |
Standard C-Mount Interface |
|
| |
| Specification of Main Body |
|
|
|
|
Infinity Optical System |
|
|
Binocular, Inclined at 30o, Interpupillary 48-75mm, Both Eyepiece Tube Diopter Adjustable |
|
Eyepiece
|
WF10x/22mm
|
|
|
Infinite Plan High Contrast Chromatic-free 4X
|
|
Infinite Plan High Contrast Chromatic-free 10X
|
|
Infinite Plan High Contrast Chromatic-free 40X
|
|
Infinite Plan High Contrast Chromatic-free 100X
|
|
|
Backward Quadruple Nosepiece
|
|
Focusing
|
Coaxial Coarse and Fine Adjustment, Fine Division0.002mm, Coarse Stroke 37.7mm/Rotation, Moving Range 24mm
|
|
|
Large Size Double Layer Mechanical Stage 216x150mm , Graphite Surface, Moving Range75mmx55mm
|
|
Condenser
|
Abbe Condensor NA1.25
|
|
Illumination
|
Kohler Illumination, 3W LED
|
| Adapter |
C-Mount 0.5x |
|
|
