MLB.003047LCD Inverted Biological Microscope, 9.7'', 5M
  • /usr/575/images/Products/Y/57519018.jpg
  •
  •
  •

Inverted LCD Laboratory Biological Microscope

  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
  • Excellent Optical Function with Infinitive Optical System.
  • Innovative Stand structure, Sharp Image Display, Convenient and Special for Viewing Incubating Cell Tissue.
9.7" LCD Pad with Andriod System of MLB.003047
Specification of LCD PAD
LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU

1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System

RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLB.003047
Head
Seidentopf Trinocular Head, 30° Inclined, Interpupillary 48~75mm, Diopter Adjustable
Optical System
Infinite optical system
Eyepiece
Extra Wide Field Eyepiece EW10x/22mm, High Eyepoint
Objective
Infinity Plan LWD Achromatic Objective 4x/0.1, W.D.18mm
Infinity Plan LWD Achromatic Objective 40x/0.6, W.D.2.6mm,Cover Glass 1.2mm
Infinity Plan Phase Contrast Achromatic Objective PH10x/0.25, W.D.10mm
Infinity Plan Phase Contrast Achromatic Objective PH20x/0.40, W.D.5.1mm
Nosepiece
Quintuple Nosepiece
Focusing
Coaxial Coarse & Fine Adjustment, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.2mm Per Rotation
Stage

* Plain Stage 160*250mm
* Glass Insert Plate
* Auxiliary Stage 70*180mm

Condenser
ELWD Condenser N.A.0.3, Long Working Distance 72mm, Up to 150mm Without Condenser
Phase Contrast
* Centering Telescope, Tube Dia.30mm
* Phase Contrast Slide, 2 Holes For 10x-20x Objective
Filters
Green, Blue, Ground Glass, Dia.45mm
Illumination
External Kohler Illumination, Halogen Lamp 6V30W, Brightness Adjustable
