MLB.001011LCD Biological Microscope, 9.7'' LCD, 5M, 40~1000X
  • /usr/575/images/Products/Y/57519025.jpg
  •
  •
  •
  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
  • Infinity optical system
  • Binocular or trinocular head inclined 30° available
  • Coaxial coarse/fine focusing system with tension adjustable and up stop
  • Kohler illumination with 6V 20W halogen lamp
9.7" LCD Pad with Andriod System of MLB.001011
Specification of LCD PAD
LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU

1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System

RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLB.001011
Eyepiece
WF10X(Φ22mm)
Head
Trinocular inclination of 30°
Objective
Infinity plan 4X/0.10
Infinity plan 10X/0.25
Infinity plan 40X/0.65(Spring)
Infinity plan 100X/1.25(Spring, oil)
Focusl System
Coaxial coarse/fine focus system, Minimum division of fine focusing: 2um
With tensional adjustable and up stop,
Nosepiece
Quadruple ,backward ball bearing inner locating
Stage
Double layer mechanical, size 210x140mm, moving range 75x50mm
Condenser
Abbe N.A.1.25 Rack & pinion adjustment
Filter
Blue filter
Frosted filter
Collector
For halogen lamp, with field diaphragm
Light source
Kohler illumination , 6V 30W halogen lamp with brightness control
