MLB.004010LCD Biological Microscope, 9.7" LCD, 5M, 40~1000X
  • /usr/575/images/Products/Y/57523134.jpg
  •
  •
  •
  • 5.0M,USB 2.0 with Android system
  • An economical model for student with a 9.7” LCD pad
  • Original integrated stand for excellent stability.
  • Unique aspheric illumination system, provide bright and comfortable lighting.
  • Various colorful matching looking can provide lively environment and happy mood.
  • Various accessories for upgrading.
9.7" LCD Pad with Andriod System of MLB.004010
Specification of LCD PAD
LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU 1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System
RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLB.004010
Head
Binocular head, inclinded 30°, rotatable 360° Interpupillary distance 50-75mm
Eyepiece
WF10X/18mm
Objective
Achromatic 4x/0.1
Achromatic 10x/0.25
Achromatic 40x/0.65
Achromatic 100x/1.25(O.S)
Nosepiece
Quadruple nosepiece
Focusing
Coaxial coarse and fine focusing knob
Stage
Double layer mechanical, size 145x140mm, moving range 76x52mm Two Slide Holder
Condenser
Abbe N.A.1.25 with aperture iris diaphragm
Filter
Built-in blue filter Φ38.5mm
Illumination
LED lamp with brightness control
Packing
1pc/carton, size 42x28x45cm, G/N weight 7/6 Kgs
