Stereo LCD Microscope, 8"LCD, 10X/20X/30X40X_IHPVISION:Microscope,Digital Vision

MLS.023076Stereo LCD Microscope, 8"LCD, 10X/20X/30X40X

Shift objectives 1X/3X、2X/4X、1X/2Xfor option.
Standard magnification 20X/40X, if use auxiliary lens and other times eyepiece, the magnification range can be 5X ~ 160X.
Standard working distance is 100mm, to create enough space for the uses.
10X large wide field eyepieces, FOV 20mm, plan and high eye-point design, more suitable for search and observation.
Observation head 45 ° inclined, diopter adjustment in two tubes, easy to operate and feel no fatigue when long time use.
Ergonomics design, shift hand wheel level (axial) bilateral settings, high repeatability precision.

Specification	MLS.023076-A	MLS.023076-B	MLS.023076-C
Magnification	10x/20x	20x/40x	10x/30x
	Up to 5~160x with Auxiliary Lens
Head	Trinocular, 45° Inclined, 360° Rotatable, +/-5° Diopter Adjustable, Interpupillary Adjustment 55~75mm
Eyepiece	WF10x/20mm, High Eyepoint
Working Distance	100mm
Stand	Pole Stand, Up/Down Range 40mm, Base Size 200x260mm, Black/White Plate Dia.100mm
Illumination	8W Fluorescent Ring Light 220V
Camera	Sensor: 1/3" CCD Horizontal Resolution: 768(H)X576(V),520 TV Line White Balance: Switch between Auto & Manual Back Light Compensation: Auto Singnal-to-Noise: More than 46db Gamma Characteristics: 0.45 Minimum Illumination: 3.1 lux Input Voltage: 12V DC (9V-14V) Power Consumption: Less than 1.85w
8" LCD Monitor	Display Dimension: 8" Display Resolution: 800x600 Visual Angle: 170/170(H/V) Horizontal: 30~61KHz Vertical: 60~75Hz Color System : 16,777,216 colors ,PAL/NTSC 4.43/NTSC 3.58/SECAM Sync.video Singal: H/V Separate, TTL,P or N 0.7V p-p@75 ohm Sound System : BG/DK/I/M Power Supply: DC 12V ,9W
