MLM.003042LCD Metallurgical Microscope, 9.7'' LCD, 5M, 40~400X
  • /usr/575/images/Products/Y/57519032.jpg
  •
  •
  •
  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
  • Big Stage with Extra Large Moving Range 250×250mm.
  • It is widely used in IT Industry for Large Area Integrate Circuit, Wafer Observation and Inspection.
  • Excellent Optical Quality with Infinite Optical System and LWD High Magnification Objective(40X/ WD3.7mm).
  • Stage Speedy Movement by Hand to Get Observation Point Immediately.
  • Comfortable and Enjoyable Operation with Low and Pre Position Control Knob.
9.7" LCD Pad with Andriod System of MLM.003042
Specification of LCD PAD
LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU 1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System
RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLM.003042
Head
Seidentopf Trinocular
Optical System
Infinity Optical System
Eyepiece EW10x/22mm, Extra Wide Field
Objective
Infinity Plan Long Working Distance Achromatic Objective 4x/ 0.1/ ∞/-
Infinity Plan Long Working Distance Achromatic Objective 10 x/0.25/ ∞/-
Infinity Plan Long Working Distance Achromatic Objective 20x/ 0.4/ ∞/-
Infinity Plan Long Working Distance Achromatic Objective 40x/ 0.6/ ∞/0
Nosepiece
Quadruple
Focusing
Coaxial Coarse & Fine Adjustment, Range24mm
Stage
Large Working Stage Size 300*268mm, Extra Large Moving Range 250*250mm,
Fast Movement, Precision Adjustment
Filter
Green, Blue,Yellow, Ground glass
Illumination
6V/ 20W Halogen Lamp, Brightness Adjustable
