Sliding Binocular Head, Inclined at 45° inclined, Interpupilary 55-75mm
|
- Digital Camera 1.3M Pixlels, 1280x1024
- USB 2.0 Output
- Operation System: Windows 2000/XP/Vista
- Software : ScopeImage Plus
- Range of Viewing Field >75%
|
|
Eyepiece
|
WF10X/ 18
|
|
|
|
|
Achromatic Objective 10x
|
|
Achromatic Objective 40x
|
|
Achromatic Objective 100x
|
|
|
Forward Quadruple Nosepiece
|
|
|
Double Layers Mechanical Stage 140X140mm/75X50mm
|
|
|
Abbe N.A.=1.20 with Iris Diaphragm & Filter
|
|
Focusing
|
Coaxial Coarse & Fine Focus Adjustment, Moving Range:28mm, Fine Division 2um
|
|
|
Halogen Lamp 6V/20W , with brightness adjustable, 110V/220V
|
