Biological Digital Microscope, 3M CMOS, USB2.0, 40X~1000X

MDB.003007Biological Digital Microscope, 3M CMOS, USB2.0, 40X~1000X

Integrated digital microscope
USB2.0 output, plug and unplug freely
Support Win8/Win7/WINDOWS 2000/XP/VISTA system, Equipped with powerful applied software
Economic features, widely used in academic demonstration and health system

Specification	MDB.003007 3M Digital Biological Microscope
Head	Seidentopf Binocular Head, Inclined at 30°, Interpupilary Distance 48-75mm
Camera System	Valid Pixel:	2048x1536（3.0M Pixel）
	Output Mode:	USB2.0
	Operation System:	WINDOWS 2000 / XP/ VISTA / Win8
	Software:	ScopeImage 9.0
	Range of Viewing Field:	90%
Eyepiece	Wide Field Eyepiece WF10X/ 18
Objective	Achromatic objectives 4x
	Achromatic objectives 10x
	Achromatic objectives 40x
	Achromatic objectives 100x
Nosepiece	Backward Quadruple Nosepiece
Stage	Double layers mechanical stage 132×142mm/ 75×40mm
Condenser	Abbe NA1.20 with Iris Diaphragm & Fliter
Focusing	Coaxial Coarse & Fine Adjustment System, Range 24mm, Fine Division 4um
Illumination	LED 3W，Brightness Adjustable

Item	Optional Accessories
Eyepiece	P16x/ 11
Illumination	Halogen Lamp 6V/ 20W，Brightness Adjustable
Polarization Set	Simple Polarization Attachment
Dark Field Attachment	Dark-field Condenser(Dry)
Dark Field Attachment	Dark-field Condenser(Immersion)
