MDB.001060Biological Digital Microscope, 1.3M CMOS, USB2.0, 40X~1000X
  • /usr/575/images/Products/Y/57517808.jpg
  • /usr/575/Picture/Y/10876.jpg
  • /usr/575/Picture/Y/10877.jpg
  •

MDB.001060 digital biological microscopes, is equipped with plan achromatic objectives and wide field eyepieces and digital trinocular. It provide clear image, wide field, convenience operation.
It can observe and display dynamic micro image at the same time.
It can be used for biology, medicine, agriculture and industry area widely. It is the ideal instruments in medical treatment, teaching demonstration and scientific research.

  • Built-in color CMOS sensor, with USB output
  • Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm
  • Kohler illumination, 6V 20W halogen lamp with brightness control
Specification
MDB.001060
Digital Head Trinocular head, built-in color 1/2" CMOS, dynamic resolution 1280X1024(UXGA) , USB2.0, system requirement: Windows 2000 @SP4 / Windows XP @SP2/ Windows vista
Eyepiece
WF10X/20mm
Objectives
 Achromatic 4X/0.10
Achromatic 10X/0.25
Achromatic 40X/0.65(Spring)
Achromatic 100X/1.25(Spring, oil)
Focus System Coaxial coarse/fine focus, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
Nosepiece
Quadruple (Frontward ball bearing inner locating)
Stage
Double layer mechanical (Size:160mmX140mm, Move range: 75mmX50mm)
Condenser
Abbe condenser N.A.=1.25, rack & pinion adjustable
Filter
Blue filter
Frosted filter
Collector
With field diagram for halogen lamp
Light source
Kohler illumination, 6V 20W halogen lamp with brightness control


Item
Optional Accessories
Eyepiece
WF16x/11mm
Dividing 10x/20mm, 0.1mm/Div
Digital Head
Trinocular head, built-in color 1/2" CMOS, dynamic resolution 1600X1200 (UXGA) ,
USB2.0, system requirement: Windows 2000 @SP4 / Windows XP @SP2/ Windows vista
Filter

Green filter
Yellow filter
