MDB.023050Biological Digital Microscope, 3M/5M CMOS, 40X~1000X
  • /usr/575/images/Products/Y/57518158.jpg
  •
  •
  •
  • High rigid but small series, specially designed for students in middle school and high school, has a light weight but stable structure.
  • 3.0M and 5.0M CMOS Digital Camera, USB 2.0 Output
  • Compact and solid, innovative frame
  • Ergonomics design
  • Support Win 8 System
Specification
MDB.023050-3M
MDB.023050-5M
Optical System Finite color corrected optical system
Digital Camera
3.0M CMOS Digital Camera
5.0M CMOS Digital Camera
Output Interface USB 2.0 Output
Head
Binocular Head, 30° Inclined, Diopter Adjustable +/-5°, Interpupillary Distance 50~75mm
Eyepiece
WF10x/18mm
Objective
Plan 4x,10x,40x(S),100x(O,S)
Nosepiece
Backward, Quarduple Nosepiece
Focusing Low Position Designed, Coaxial Coarse & Fine Focusing, Coarse Focusing Range 25mm, Fine Focusing Scale 0.002mm, With Tension Adjustment, With Upper Safty Stop
Stage Double Layer Mechanical Stage, Size 132*140mm, Moving Range 50*76mm, Precision 0.1mm
Condenser Abbe N.A.1.25, With Iris Diaphragm, Fixed But Centeradjustable
Light Source 3W LED High Brightness
Power Wide Voltage AC100~240V Input, DC 6V1A Output
Operating System
Microsoft Windows XP / Vista / win7 (32 & 64 bit) / win8 (32 & 64 bit)
