MDB.017014Digital Biological Microscope, 3M CMOS, USB2.0, 40X~1600X
  • /usr/575/images/Products/Y/57518721.jpg
  • /usr/575/Picture/Y/11527.jpg
  •
  •
  • 3.0M CMOS Digital Camera
  • USB 2.0 Output
Specification
MDB.017014
Digital Camera
3.0M 1/2"CMOS Digital Camera
Output Interface USB 2.0 Output
Head
Binocular head(built-in digital camera system), 30° inclined, 360° rotatable
Eyepiece WF10X/16X
Objective
Achromatic 4X,10X,40Xs,100Xs
Focusing
Coarse Adjustment Range: 20mm
Working Stage
Mechanical stage: 130mm*140mm
Condenser
N.A.1.25 , Iris Diaphragm
Photo attachment
Built-in 1/2"CMOS device, Effective Pixels:3MP, USB connecting Socket
Light Source
Blue filter
Halogen lamp 6V/20W, adjustable brightness
Operating System
Microsoft Windows XP/ Win7
