MBL.040031Compound Microscope, 40X~1000X ,large stage

High efficiency,flexibility and stability are the characters of this series microscope.It is specially developed for various application fields.It is widely used,from daily work to scientific research,in laboratory,hospital and college.Because of higher cost performance and reasonable humanized design,it becomes the first choice of individual,hospital and scientific research organization.

Specification	MBL.040031	MBL.040031-T
Head	Compensation free binocular head,inclined at 30°（48mm-75mm）	Compensation free binocular head,inclined at 30°（48mm-75mm）
Eyepiece	WF10×/22mm
Objective	Infinite Semi-Plan objective 4X
	Infinite Semi-Plan objective 10X
	Infinite Semi-Plan objective 40X, Spring
	Infinite Semi-Plan objective 100X/Oil, Spring
Nosepiece	Quintuple Revolving Nosepiece
Focusing	Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm
Stage	Double Layer Mechanical,Size 180mmX160mm,Moving Range80mmx50mm
Collector	Kohler Illumination
Condenser	N.A.1.25Abbe condenser with iris diaphragm & filter holder
Light Source	Halogen Bulb12V/30W,AC 85-230V, Adjustble Brightness

Item	Optional Accessories
Eyepiece	WF16X
	WF 20X
	P16X
Objective	Infinity Semi-Plan Achromatic 20X(S),60X(S)
Objective	Infinity Plan Achromatic 4×、10× 、20× 、40×(s)、60×(s)、100×(s)Oil
Attachment	Photography attachment
	Phase Contrast Attachment
	CCD C-mount:0.5X、0.57X、0.75X、1X
