MSG.023001 Jewelry Microscope can fulfill transmission bright field, reflection bring field, polarized observation and dark field observation to help you indentify a full range of jewerly samples.
|
Specification
|
MSG.023001 Jewelry Microscope 6.7x-45x
|
| Magnification | 6.7~45x, with Auxiliary Lens, it can reach 2x~225x |
|
Head
|
Binocular Viewing Head, 45° Inclined, 360° Rotatable, +/-5° Diopter Adjustable, Interpupillary 54~75mm
|
|
Eyepiece
|
WF10x/22mm
|
|
Zoom Range
|
0.67~4.5x
|
|
Zoom Ratio
|
1:6.7
|
|
Working Distance
|
With Standard 1x Lens： W.D.:100mm; With Auxiliary Lens: W.D. reach 26~287mm
|
|
Stand
|
Retroverted 45 degree
|
|
Gem Clamp
|
Wire Clamp For Bigger Objects, Flat Clamp For Smaller Objects |
|
Focusing
|
Focusing range: 110mm; 0- 45 degree rotatable; Dark and bright feild are available.
|
|
Illumination
|
Reflected Light source:1W High Power LED, brinhtness adjustabl or e7W Fluorescent lamp
|
|
transmitted Light Source: 6V/30W Halogen Philips Lamp, brinhtness adjustable
|
