Specification
|
MAC.002021
|
|
Sensor
|
TCD1304 (1D Toshiba CCD)
|
|
Senser Size
|
29.184mm
|
| Pixel Size |
8μm x 200μm
|
| Max.Resolution |
3648 Pixels
|
| Spectral Range |
300-1000nm
|
| A/D Converter |
16-bit to PC
|
| Sensitivity |
200 V/lx.s with Daylight Fluorescent Lamp
|
| Output Rate |
1.0MHZ
|
| Exposure Range |
3.8-4000ms
|
| External Trigger |
Supported
|
| Capture/Control API |
SDK and Example Code
|
| Capture Mode |
Single Camera Multiple Instance and Multiple Cameras Supported
|
| Host Interface |
USB2.0
|
| Power Supply |
Over USB Port
|
| Capture Mode |
Still Picture and Video
|
| Color Rendering Technique |
Ultra FineTM Color Engine
|
| Lens Mount |
M42
|
| Operating System |
Microsoft Windows XP / Vista / 7 (32 & 64 bit)
CPU: Equal to Intel Core2 2.8GHz or Higher Memory:2GB or More USBPort:USB2.0 High-speed Port |
| Remarks |
Actual frame rates on your computer depend on the hardware and operating system used
|
| Operating Temp. |
-30~70℃
|
| Storage Temperature |
-40~85℃
|
| Operating Humidity |
30%~80%RH
|
| Storage Humidity |
10%~60%RH
|
| Package Box |
140mmx140mmx80mm, 0.5Kgs
|
