MAC.002018-B
|
MAC.002018-C
|
MAC.002018-D
|
| Resolution |
2M, 1920x1080
|
0.8M, 1280x720
|
0.3M, 640x480
|
|
Sensor
|
MT9P001(C),1/2.5"(5.70x4.28)
|
MT9V011(C),
1/4"(3.58x2.69)
|
| Pixel Size |
2.2x2.2um
|
5.6x5.6um
|
|
Frame Rate
|
15fps@1080P
|
30fps@720P
|
10fps@720P
|
25fps@640x480
|
| G Sensitivity |
1.0 V/lux-sec
|
1.9V/lux-sec
|
| Dynamic Range |
61dB
|
60dB
|
| SN Ratio |
43dB
|
45dB
|
| Binning |
2x2
|
1x1
|
| Exposure |
0.21ms~200ms
|
Auto
|
| Spectral Range |
380-650nm (with IR-filter) |
| White Balance |
White Balance /Manual Temp Tint Adjustment |
| Color Rendering Technique |
Ultra Fine Color Engine(Embeded on Board) |
| Capture/Control API |
Native C/C++, C# for Windows Operating System |
| Recording System |
Still Picture and Movie |
| Cooling System* |
Natural |
| Operating Temperature |
-10℃~ 50℃ |
| Storage Temperature |
-20℃~ 60℃ |
| Operating Humidity |
30~80%RH |
| Storage Humidity |
10~60%RH |
| Power Supply |
USB Charger or Over PC USB Port |
| Operating System |
Support Microsoft Windows XP / Vista / 7 /8 (32 & 64 bit)
IOS IPAD or IPhone, Android PAD of Phone |
| PC Requirements |
- CPU: Equal to Intel Core2 2.8GHz or Higher
- Memory: 2GB or More
- WIFI Adaptor with DHCP Enabled
- Display: 17" or Larger
- Ability to Play 0.35M MJPEG Format Video Smoothly
- CD-ROM
|
