3.1M
|
5.1M
|
8.5M
|
10M
|
14M
|
| Resolution |
2048x1534 |
2560x1922 |
3328x2548 |
3584x2746 |
4096x3286 |
| Sensor |
1/3“ (4.51x3.38) |
1/2.5“ (5.70x4.28) |
1/2.4“(5.56x4.26) |
1/2.3“(5.98x4.58)) |
1/2.3“(5.73x4.60) |
| Pixel Size (um) |
2.2x2.2 |
2.2x2.2 |
1.67x1.67 |
1.67x1.67 |
1.4x1.4 |
| Frame Rate |
27.3@2048x1534
53.3@1024x770 |
14.2@2560x1922
38.3@1280x960
101.2@640x480 |
8.3@3328x2548
26.2@1664x1272 |
7.2@3584x2746
24.5@1792x1372 |
6.2@4096x3286
20.8@2048x1644
53.3@1024x822 |
| Binning |
1x1,2x2 |
1x1,2x2,4x4 |
1x1,2x2,4x4 |
1x1,2x2,4x4 |
1x1,2x2,4x4 |
| Exposure(ms) |
0.1~2000 |
0.1~2000 |
0.1~2000 |
0.4~2000 |
0.4~2000 |
| |
16M
|
16MPB
|
16MMB
|
|
|
| Resolution |
4632x3488 |
4648x3506 |
4648x3506 |
|
|
| Sensor |
1/2.33“(6.18x4.66) |
4/3“ (17.60x13.30) |
4/3“ (17.60x13.30) |
|
|
| Pixel Size (um) |
1.335x1.335 |
3.8x3.8 |
3.8x3.8 |
|
|
| Frame Rate |
6.0@4632x3488
15.0@2320x1740
26.0@1536x1160 |
6.0@4648x3506
15.0@2304x1750
30.0@1536x1168 |
22@4648x3506
43@2304x1750
49@1536x1168 |
|
|
| Binning |
1x1,2x2,3x3 |
1x1,2x2,3x3 |
1x1,2x2,3x3 |
|
|
| Exposure(ms) |
0.2~2000 |
0.06~15000 |
0.06~15000 |
|
|
| |
|
| Spectral Range |
380-650nm (with IR-cut Filter) |
| White Balance |
ROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor |
| Color Technique |
Ultra-FineTMColor Engine/NA for Monochromatic Sensor |
| Capture/Control API |
Native C/C++, C#/VB.NET, DirectShow, Twain and Labview |
| Recording System |
Still Picture and Movie |
| Cooling System* |
Natural |
| Interface |
USB3.0 |
| Operating Temperature |
-10℃~ 50℃ |
| Storage Temperature |
-20℃~ 60℃ |
| Operating Humidity |
30~80%RH |
| Storage Humidity |
10~60%RH |
| Power Supply |
DC 5V over PC USB Port |
| Operating System |
Microsoft Windows \XP/ Vista / 7 / 8 /10 (32 & 64 bit)
OSx(Mac OS X) Linux |
|
PC Requirements
|
- CPU: Equal to Intel Core2 2.8GHz or Higher
- Memory: 2GB or More
- USB Port:USB3..0 High-speed Port
- Display: 17" or Larger
- CD-ROM
|
|
