MOC.036005-FT
|
MOC.036005-FTB
|
MOC.036005-FRB
|
| Head |
45° Tilted |
From -40° to 80° |
| Eyepiece |
12.5X;Interpupillary distance 50mm-80mm; Diopter ±5D |
| Focal Length Of Objective |
300mm |
| Magnification Changer |
5-step magnification change: 0.4x, 0.6x, 1x, 1.6x, 2.5x |
| Total magnification |
1.9X, 2.8X, 4.8X, 7.6X, 12X |
3.3X, 5X, 8.3X, 13.3X, 20.8X |
| Linear field |
1.9X, 2.8X, 4.8X, 7.6X, 12X |
90mm, 60mm, 38mm, 24mm, 17mm |
| Fine focusing distance |
20mm |
| Balanced arm |
Counterweight adjustable |
| Illumination system |
21V150W halogen lamp, brightness adjustable |
| Filter |
Built in green filter |
| Stand |
Short column fitted on the round base with 5 jaws |
| Beamsplitter |
NO
|
50:50 Beamsplitter
|
50:50 Beamsplitter
|
| TV adapter |
NO
|
C-mount 1/3” CCD camera attachable
|
C-mount 1/3” CCD camera attachable
|
| Demonstrator |
NO
|
Optional
|
Yes
|
| CCD camera |
NO
|
Optional
|
Optional
|
|
Photo adapter
|
NO
|
Optional
|
Optional
|
|
