MLP.001076Polarizing LCD Microscope, 9"LCD, 5M CMOS, HDMI, 50X~600X
  • /usr/575/images/Products/Y/57518577.jpg
  •
  •
  •
  • 9” LCD HD Screen,1280X800
  • 5M CMOS Camera,2560X1920
  • HDMI Output,4G SD Card
  • Equipped with infinity plan objectives (strain-free) and wide field eyepiece
  • Coaxial coarse/fine focus system with tensional adjustable and up stop, minimum division of fine focusing: 2μm
  • Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and withtightener,Stage vertical effective movement up to 30mm
  • Wide voltage range power supply (85-265V 47-60HZ), 6V30W halogen lamp, brightness adjustable
Specification
MLP.001076 9" HD LCD ,5M CMOS Polaringz Microscope
Eyepiece
Wide field WF10X
Dividing Eyepiece 0.10mm/Div
Head
Binocular, Inclination 30°
Infinity Plan Objective, Strain-free
PLL 5X/0.12, WD 26.1mm, no cover glass
PLL 10X/0.25, WD 20.2mm, no cover glass
PLL 40X/0.60, WD 3.98mm, no cover glass
PLL 60X/0.70 , WD 3.18mm, no cover glass
Focusl System
Coaxial coarse/fine system, with tension adjustable and up stop, minimum division of fine focusing: 2um
Nosepiece
Quadruple(Backward ball bearing inner locating);the Center of Objective is Adjustable
Intermediate
Puller Type Bertrand Lens and Center Adjustable
Compensator
λ compensator
λ/4 compensator
Quarts wedge compensator
Stage
Rotatable stage, Diameter Φ150mm, 360°graduated (in 1° increments), minimum retardation resolution 6' center adjustable and with tightener
Reflected Illumination
Polarizer 360 Degree rotatable,can Be Move Out or Into Optical Path
Analyzer 360 Degree rotatable,rotated From 0°to 360°
with scale and minimum vernier
Integrated Field and Aperture Diaphragm
Illumination 6V 30w, halogen lamp, adjustable brightness
Iillumination
Polarizer 360° rotatable, have 0,90,180,270 four scale
Collector for halogen lamp illumination
Illumination 6V 30w, halogen lamp, adjustable brightness
Wide Voltage Range Power Supply (85-265V 50/60Hz)
Abbe condenser rack & pinion adjustable

Digital System
LCD Screen 9 HD Inches, Resolution is 1280*800
Image Sensor 5.0 Mega
Photo Resolution 2560X1920
Video Resolution 1280X720/30FPS
Data Output HDMI
Storage 4G Card
Date Mode Year, Month, Day, Hour, Minute
Measurement&Positioning Crosshair and Arrow (Black,White,Red,Green,Blue)
Language

Nine Languages (English,Germany,French,Spanish,Russia,
Janpanese,Korean,Latin,Arabic)

Coordinate Colors Black/White/Red/Blue/Green

Item
Optional Accessories
Infinity Plan Objective, Strain-free
(No Cover Glass)

PL L 20X/0.40 (Working Distance): 8.80mm
PL L 50X/0.70 (Working Distance): 3.68mm
PL L 80X/0.80 (Working Distance): 1.25mm
PL L 100X/0.85 (Working Distance): 0.4mm
