LCD Polarizing Microscope, 9.7'' LCD, 5M, 50~500X, Reflected and Transmitetd Illumination

Home > Products > LCD Microscope > LCD Polarizing Microscope

MLP.038006LCD Polarizing Microscope, 9.7'' LCD, 5M, 50~500X, Reflected and Transmitetd Illumination

LCD Polarizing Microscope
9.7’’ LCD Screen,resolution 1024*768
5.0M CMOS Image Sensor built-in
Infinity independent achromatic optical system,50X~500X
Reflected and Transmitetd Illumination

9.7" LCD Pad with Andriod System of MLP.038006
Specification of LCD PAD	LCD Screen	9.7" HD Diagonal IPS LCD Resolution 1024*768 Backlight Screen, Five Point Touch Screen, Hardware Power Switch
	CPU	1.6GHz Four Core ARM Mali-400 MP GPU Support OpenGL ES 1.1/2.0 And OpenVG 1.1 Support Full HD 1080p Support Android 4.2 System
	RAM	2GB, Support DDR3, DDR2, LPDDR2
	Data Storage	SD Card Slot, Support Max 32GB C10 High Speed SD Card
	Data Interface	HDMI, Mini USB2.0, USB 2.0
	Operation System	Android 4.2 System, Multi Language
	Power	Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor, Power Mode : Normal, Sleep, Power Off
	WIFI	Support
	Bluetooth	Support
	Software	YX Camera Installed, --Can Adjust Real Time Image --Can Measure Length, Area, Angle, Count --Can Take Picture, Record Video YX Image Installed --Grey, Contrast, Brightness Adjust --Binary Image For Granular Count Both Software Chinese/English Version, With Instruction Manual Installed
	Product Size	Pad 17.522.52.0cm
	Package Size	Packing Box 102429cm, 1 pc/Box
Specification of Digital Camera	Senser	1/2.5" CMOS, Color, Aptina MT9P001
	Resolution	5.0M Pixels, Maximum Photo Resolution 2592*1944
	Pixel Size	2.2um*2.2 um
	Effective Image Size	5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
	Frame Rate	1280720/15 Fps, 640480/30Fps
	Dynamic Range	66.5dB
	SNR	40.5dB Max
	ADC	12 Bit, On Chip
	Shutter Type	ERS, Auto
	White Balance	Auto
	Connect	Standard C-Mount Interface

Specification of Main Body	Specification	Main Body of MLP.038006
	Magnification	50x - 500x
	Optical System	UCIS infinity independent achromatic optical system
	Head	Seidentopf trinocular head 30° inclined, rotatable 360°,interpupillary distance 52-75mm
	Eyepiece	Plan WF10x/20mm, high eyepoint up to 21mm,
	Eyepiece	Plan WF10x/20mm, polarizing reticule eyepiece
	Objective	Infinity achromatic objectives 5X
		Infinity achromatic objectives 10X
		Infinity achromatic objectives 20X
		Infinity achromatic objectives 50X
	Nosepiece	Quadruple, reversed type with positive click stops
	Focusing	Low positioned, coaxial coarse&fine focusing system with an adjustable tension control and upper limit stop, coarse 14mm/rot,fine 0.1mm/rot, minimum reading 1μm on left-side fine knob, moving range 20mm
	Stage	Specimen holder
	Stage	Rotating stage, size 142mm, pre-centered and 360° rotatable
	Condenser	Swing-Out Condenser N.A.1.25
	Polarization	The polarizer mounted under the condenser holder rotates 360° with click stops every 45°, scale 0°45°90°135°180°225°270°315°
	Polarization	The Intermediate tube has a analyzer with large rotation control dial for easy adjustment and accurate reading through rotations of 180°,division 1°,accuracy 6'. The built-in focusable and centerable Bertrand lens allows conoscopic observation. with compensator slot
	Compensator	Quartz wedge plate, I-IV class
		λ Plate, first class red
		1/4λ Plate
	Filter	Blue Φ38
	Adapter	0.5x, C-Mount
	Kohler Illumination	with field diaphragm
	Reflected Illumination	12V50W Power supply unit
		12V100 Halogen lamp house
		Reflected illuminator (single module)
		Polarizer slider for reflected illuminator
	Transmitetd Illumination	6V20W Halogen lamp, 110-240V wide voltage
		6V20W halogen bulb (Osram)
		250x/3.15A Φ5x20 fuse
	Other	Immersion Oil
		Φ2mm Allen Screw Driver
		Φ1.5mm Allen Screw Driver
		Dust cover
		Power cord
