| Magnification |
2x~240x |
| Head |
Bionocular Head, 30° Incline, Interpupilary Distance 48~75mm, Diopter +/-5 Adjustable |
|
Eyepiece
|
WF10x/22mm, High Eyepoint |
WF20x/12mm, High Eyepoint
|
|
|
LWD Infinity Plan Achromatic Objective 0.5X |
| LWD Infinity Plan Achromatic Objective 1X |
| LWD Infinity Plan Achromatic Objective 1.5X |
| LWD Infinity Plan Achromatic Objective 2X |
| LWD Infinity Plan Achromatic Objective 4X |
| LWD Infinity Plan Achromatic Objective 6X |
|
|
0.4x
|
| 2X |
|
View Field
|
Dia. 2.3~62mm
|
| Nosepiece |
6 Hole Click Stop Nosepiece |
|
Working Stage
|
Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm |
| Round Titable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable |
|
Square Manual Working Stage 90*90mm, Moving Range 54*54*54mm
|
| Bullet Holder |
Bullet Holder Set for all kinds of Bullet, Cartridge and other Objects |
|
Light Source
|
5W LED Cold Light, High Brightness, Brightness Adjustable
|
| 12V50W Fan Cooling Strong Halogen Light, Brightness Adjustable |
|
Coaxial Light Lens, to observe in deep hole, or smooth object surface
|
| Polarizing Light Lens, to eliminate flare lights and dazzling lights |
| Transmit Bottom Light |
| Ultraviolet Light Lens |
| Filters: Red, Blue, Yellow, Green |
| Working Distance |
101mm |
|
Separation Line Adjust
|
Seperation Line Adjust System in Back, with Special Designed Adjust Driver |
| Magnification Correct |
Magnification Correction System, with Correcting Lens
|
|
|
Built-in 3.0M High Resolution Color CCD Camera, USB 2.0 Output, 2048*1536 Pixels, Pixel Size 3.2*3.2um |
| Adapter |
Front View Photo Adapter for SLR Digital Camera
For user to view and take photo easily
|
|
0.5x CCD Adapter
|
|
Power
|
80~240V Wide Range Voltage
|
|
Dimension
|
Instrument Size 43*34*65cm
|
|
Packing
|
Strong Aluminum Case + Carton, Size 85*50*68, G.W. 65 Kgs
|
