8M Digital Camera Parameters
|
| Resolution |
8M,3840*2160 |
| Sensor |
SONY IMX274 CMOS |
| Expose Mode |
Rolling Shutter |
| Sensor Optical Format |
1/2.5" |
| Pixel Size |
1.62um*1.62um |
| Dynamic Range |
＞80db |
| SNRMAX |
≥50db |
| Spectral Charactristics |
380-650nm |
| Exposure Capability |
Real-time, Single auto, Manual adjustment |
| White Balance |
Real-time, Single auto, Manual adjustment RGB seperately |
| Record Format |
Snapshot |
| Picture Format:? |
JPG Resolution 3840*2160 |
| Video Format |
MOV,Resolution 3840*2160@25fps,2592*1944@25fps,2048*1536@25fps |
| |
Optical Parameters
|
| Optical Magnification of Lines |
0.83-10x |
| Optical Resolution n of Lines |
5um |
| Working Distance(mm) |
72mm |
| Observation Range(mm) |
0.65*0.36-8.2*4.6mm |
| Comprehensive Magnification |
Full Screen Display on a 21 inch 16:9 monitor 57x-715x |
| Full Screen Display on a 17 inch 16:9 monitor 46x-578x |
| Working Stage |
Square Manual Working Stage 120*120*43mm, Moving Range 55*55*55mm |
| Round Working Stage Dia: 100m, 360 degree Rotatable |
| Round Titable Working Stage Moving Range0-14.5mm,45-90 inclined, 360dgree Rotatable |
| |
Dual Ring LED Light Source
|
| Colour Temperature |
5000-5500k |
| Power |
＜3W |
| Input Voltage |
DC 5V |
| Dimming Method |
0-100% Linear Adjustment |
| Centric Brightness |
Coaxial? ≥12000LX |
| Diffuse Reflection ≥42000LX |
| Number of LEDs |
Coaxial Light: 13 Small Angle Highlighting Lamp |
| Diffuse Light: 40 Bright White LEDs |
| Adjustment Method |
Separate Control |
| |
7-Color LED light source
|
| Power |
＜3W |
| Input Voltage |
DC 5V |
| Dimming Method |
0-100% Linear Adjustment |
| LED Wavelength |
Red: 620-625um |
| Yellow: 590-595um |
| Green: 520-525um |
| Blue: 460-465um |
| Purple: 390-400um |
| White: 6000k |
| Adjustment Method |
Brightness is adjustable seperately |
| |
Software Enviroment
|
| Window System Demand |
Microscope Windows XP/7/8/8.1/10(32&64 Bit) |
| CUP: Dual-core 3.0G or better |
| Memory: 4G or better |
| Hard Space: 10GB at least |
| Network:10/100/1000Mbps Compatitable Interface |
| |
Operating Environment
|
| Operating Temperature |
0-40 degree |
| Storage Temperature |
-20℃-60℃ |
| Operating Humidity |
30-60%RH |
| Storage? Humidity |
10-80%RH |
