MLC.050003LCD Comparison, 2.5x~160x, 9.7'' LCD, 5M CMOS
  • /usr/575/images/Products/Y/57519188.jpg
  •
  •
  •

This forensic comparison microscope can use the same set of eyepiece to observe objects in left and right field. Two or more images of objective can be compared through overlap them. Because of its clear imaging, high resolution, it can identify the small differences of some objects. It is widely used to identification of bullets, tool marks, fingerprint, seal, text, currency.

  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
9.7" LCD Pad with Andriod System of MLC.050003
Specification of LCD PAD
LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU 1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System
RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLC.050003
Magnification 2.5x~160x
Head
Bionocular Head, 30° Incline, Interpupilary Distance 50~75mm, Diopter +/-5 Adjustable
Eyepiece
WF10x/23mm, High Eyepoint
WF20x/12mm, High Eyepoint
Objective
5 Step Zoom Plan Objective 0.64x, 1.0x, 1.6x, 2.5x, 4.0x
Auxiliary Lens
0.4x
2X
View Field
Dia. 2.0~90mm
Nosepiece 6 Hole Click Stop Nosepiece
Working Stage
Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm
Round Titable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable
Square Manual Working Stage 100*100mm, Moving Range 54*54*54mm
Bullet Holder Bullet Holder Set for all kinds of Bullet, Cartridge and other Objects
Light Source
5W LED Warm Light, High Brightness, Brightness Adjustable
5W LED Cold Light, High Brightness, Brightness Adjustable
Coaxial Light Lens, to observe in deep hole, or smooth object surface
Polarizing Light Lens, to eliminate flare lights and dazzling lights
Transmit Bottom Light
Ultraviolet Light Lens
Filters: Red, Blue, Yellow, Green
Working Distance 100mm
Separation Line Adjust
Seperation Line Adjust System in Back, with Special Designed Adjust Driver
Magnification Correct
Magnification Correction System, with Correcting Lens
Adapter
Photo Adapter for SLR Digital Camera
0.5x CCD Adapter
Power
80~240V Wide Range Voltage
Dimension
Instrument Size 38*31*65cm
