MLC.043001LCD Comparison, 3.8x~230x, 9.7''LCD, 5M CMOS
  • /usr/575/images/Products/Y/57519189.jpg
  • /usr/575/Picture/Y/11569.jpg
  •
  •

Comparison microscope is a special instrument , which can observe the images of both the left and right objects at the same time through two eyepieces, and make a macro or micro comparison on two or more objects. This instrument is used for a wide range of forensic investigations including ballistics, toolmark, and document comparison.

  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
  • Total magnification: 3.8X-115X
  • Working distance: 101mm
  • View-field: φ2.3mm-φ62mm
  • Object stage : X-axial movement:54mm, Y-axial movement :54mm
  • horizontal rotation angle :0°-360°,inclined range of stage surface: 0°-60°adjustable
  • Horizontal linking-up range between two object stages: 54mm
  • Longitudinal linking-up range between two object stages: 54mm
  • Illuminating : 12V50W fan-cold strong light source and LED cold light source
  • Polarization device: eliminate flare lights and dazzling lights
  • Coaxial light device: observation on deep hole, small hole and smooth object surface
  • Photographing device : attached with photography tube for taking a photo.
9.7" LCD Pad with Andriod System of MLC.043001 Comparison Microscope
Specification of LCD PAD
 LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU 1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System
RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser 1/2.5" CMOS, Color, Aptina MT9P001
Resolution
 5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLC.043001 Comparison Microscope
Magnification
 3.8x~230x
Head
Bionocular Head, 30° Incline, Interpupilary Distance 48~75mm, Diopter +/-5 Adjustable
Eyepiece
WF10x/22mm, High Eyepoint
WF20x/12mm, High Eyepoint
Objective
5 Step Zoom Plan Objective 0.8x, 1.25x, 2x, 3.2x, 4.8x
Auxiliary Lens 0.4x, 2.0x
View Field
Dia. 2.3~62mm
Working Distance
101mm
Magnification Correcting
Magnification Correction System, with Correcting Lens
Separation Line Adjusting
 Seperation Line Adjust System in Back, with Special Designed Adjust Driver
Working Stage
Square Manual Working Stage 90*90mm, Moving Range 54*54*54mm
Round Titable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable
Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm
Light Source
12V50W Fan Cooling Strong Halogen Light, Brightness Adjustable
5W LED Cold Light, High Brightness, Brightness Adjustable
Coaxial Light Lens, to observe in deep hole, or smooth object surface
Polarizing Light Lens, to eliminate flare lights and dazzling lights
Ultraviolet Light Lens
Filters
Red, Blue, Yellow, Green
Adapter
0.5x CCD Adapter
Front View Photo Adapter for SLR Digital Camera
Power
80~240V Wide Range Voltage
Instrument Dimension
 37*30*63cm
